Mac Studio MAX

Apple M1 Max chip

• 10-core CPU with 8 performance cores and 2 efficiency cores
• 24-core GPU
• 16-core Neural Engine
• 400GB/s memory bandwidth

Media engine

• Hardware-accelerated H.264, HEVC, ProRes, and ProRes RAW
• Video decode engine
• Two video encode engines
• Two ProRes encode and decode engines

Configurable to:

M1 Max with 10-core CPU, 32-core GPU, and 16-core Neural Engine

Video Support

Simultaneously supports up to five displays:

• Support for up to four Pro Display XDRs (6K resolution at 60Hz and over a billion colors) over USB-C and one 4K display (4K resolution at 60Hz and over a billion colors) over HDMI

Thunderbolt 4 digital video output supports

• Native DisplayPort output over USB‑C
• Thunderbolt 2, DVI, and VGA output supported using adapters (sold separately)

HDMI display video output

• Support for one display with up to 4K resolution at 60Hz
• DVI output using HDMI to DVI Adapter (sold separately)

Thunderbolt 4

10Gb Ethernet

USB-A

HDMI

3.5 mm headphone jack

Four Thunderbolt 4 ports with support for:

• Thunderbolt 4 (up to 40Gb/s)
• DisplayPort
• USB 4 (up to 40Gb/s)
• USB 3.1 Gen 2 (up to 10Gb/s)

• Two USB-A ports (up to 5Gb/s)
• HDMI port
• 10Gb Ethernet
• 3.5 mm headphone jack

On front (M1 Max):

• Two USB-C ports (up to 10Gb/s)
• SDXC card slot (UHS-II)

On front (M1 Ultra):

• Two Thunderbolt 4 ports (up to 40Gb/s)
• SDXC card slot (UHS-II)
